Goodix's health sensors product family combines a series of integrated and discrete products. Our optical modules enable Photo Plethysmo Graphy (PPG), supporting heart rate(HR), heart rate variability (HRV) and oxygen saturation (SpO2) detections, while the analog front-end (AFE) can provide high-precision and low-power consumption measurements including electrocardiogram (ECG), bioelectrical impedance analysis (BIA), and electrodermal activity (EDA) to help users achieve more vital signs monitoring. Goodix offers customers with hardware, software, mechanical and optical design guidelines, as well as algorithms to accelerate the time to market of customer products.
Goodix Health Sensors Introduction
Safeguard Your Health Through Innovation--Keynote Speech of Goodix Innovative Health Sensor Solution
Goodix Health Sensors Introduction
Safeguard Your Health Through Innovation--Keynote Speech of Goodix Innovative Health Sensor Solution
| Product Type | P.N. | PPG TX | PPG RX | ECG | Bio-Z | Temperature | Force detecting | Interface | Package | Size(mm) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LED Channels | Max LED current | AFE channels | PD channels | ECG channels | BIA channels | EDA channels | RESP channels | NTC channels | Force detecting channels | |||||
| Optical Module | GH3011 | 3 | 100 mA | 1 | 1 | / | / | / | / | / | / | IIC/SPI | LGA 19 | 3 * 4 * 0.8 |
| PPG AFE | GH3020 | 8 | 200 mA * 2 | 4 | 8 Single/ 4 Diff | / | / | / | / | / | / | IIC/SPI | WLCSP-42 | 2.6 * 2.9 * 0.46 |
| GH3026 | 8 | 200 mA * 2 | 2 | 8 Single/ 4 Diff | / | / | / | / | / | / | IIC/SPI | WLCSP-42 | 2.6 * 2.9 * 0.46 | |
| Multi-modal AFE | GH3300 |
16 | 200 mA * 4 | 4 | 8 Single/ 4 Diff | 1( DC or AC) | 1 | 1 | 1 | 4 | / | IIC/SPI | WLCSP-49 | 2.645 * 2.645 * 0.5 |
| GH3220 | 8 | 200 mA * 2 | 4 | 8 Single/ 4 Diff | 1 | / | / | / | / | / | IIC/SPI | WLCSP-42 | 2.6 * 2.9 * 0.46 | |
| GH3220T | 8 | 200 mA * 2 | 4 | 5 Single/ 2 Diff | 1 | / | / | / | 3 | / | IIC/SPI | WLCSP-42 | 2.6 * 2.9 * 0.46 | |
| GH7530 |
/ | / | / | / | 3 | / | / | 1 | 2 | / | IIC/SPI | QFN48 | 6 * 6 | |
| GH7339 |
4 | 200 mA * 4 | 1 | 4 Single/ 2 Diff | 3 | / | / | 1 | 2 | / | IIC/SPI | QFN48 | 6 * 6 | |
| GH3500 |
/ | / | / | / | 2 | 1 | 1 | / | 4 | 2 | IIC/SPI | QFN48 | 6 * 6 | |
| GH3400 |
/ | / | / | / | / | 1 | 1 | / | 4 | 2 | IIC/SPI | QFN48 | 6 * 6 | |
SDKs
Hardware resources
Development tools
Documents
Mass production test
Supporting
A wide range of high-performance and cost-effective models at your choice
Ready-to-go solutions with chips and core algorithms
Industry-leading performance for precise and reliable measurement
Large-scale mass production experience for stable and timely delivery
